Category :
Hydraulic power steering pump
Ref : P1950
Family :PA
Axle diameter : 19 mm
Manufacturer : LUK
Height : 165 mm
Steering wheel position : Left-hand drive
Presence of the pulley : Without
Presence of the reservoir : Without
Presence of the support : With
Type of material : Aluminium
INSTRUCTION MONTAGE
Maximum pressure : 110.0 bar
JOINT TORIQUE
Outer diameter : 16 mm
Inner diameter : 2.04 mm
SUPPORT POULIE
Centre bore diameter : 30 mm
Mounting hole diameter : 8 mm
Diamètre extérieur : 63.9 mm
Centre distance : 45 mm
Shape : Star-shaped
Number of mounting holes : 3
Equivalence to manufacturer references
BMW : 32411093577
BMW : 32411137952
