FIESTA V FUSION/MAZDA 2 G

Name: FIESTA V FUSION/MAZDA 2 G
Brand: ATI
SKU: 35301
Price: 207.6 EUR
Availability: InStock

Ref : 35301

Family :TR

Compressed length : 618 mm

ABS on the vehicle : Yes

COTE BOITE

Number of external splines : 23

Seal seat diameter : 40 mm

Length of the gearbox output without seal seat : 62 mm

Housing diameter : 64 mm

Outer spline diameter : 25.5 mm

COTE ROUE

Number of splines on inner race : 20

Nombre de cannelures extérieures : 25

Type and position (snap ring/circlip) : Centered snap ring

Shoulder diameter : 53 mm

Diamètre du bol : 72 mm

Equivalence to manufacturer references
