Search by vehicle
Category :
Transmission
Equivalence to manufacturer references
-
SEAT : SE022141920A
SEAT IBIZA D
Ref : 53410
Family :TR
Compressed length : 887 mm
ABS on the vehicle : No
ARBRE (TRANSMISSION) GENERAL
Number of splines :
JOINT HOMOCINETIQUE COTE ROUE
Outer spline diameter : 24 mm
Housing diameter : 81 mm
Shoulder diameter : 48 mm
Number of external splines : 22
Number of splines on inner race : 20
Type and position (snap ring/circlip) : External snap ring
| Sealing kit | COTE ROUE | S5006 |
|
| COTE BOITE | S6026 |
|
|
| CV joint | COTE ROUE | JHSE41 |
|
| JHSE41 |
|
||
| Fixation | ATEC004 |
|
